CFN10P455N04FB

ITEMS

SPEC

UNIT

Center Frequency [fo]

455.250

MHz

Bandwidth [BW]

fo ±2.250  [453.000  ~  457.500]

MHz

Insertion Loss in BW

3.5

dB max

Ripple in BW

          0.8   TYP: 0.5

dB max

Return Loss in BW

15.0

dB min

Attenuation

   RAbsolute Value

   £Relative  Value

4.0 dB min.  @ fo + 5.0 [       &  460.225 ]

MHz

20.0 dB min.  @ fo + 8.075 [     &  463.300 ]

MHz

40.0 dB min.  @ fo - 115.0 [340.225  & ]

MHz

35.0 dB min.  @ fo - 105.0 [350.225  & ]

MHz

Group Delay Variation

ns max

Input Power

1.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃  to  +85℃
