CFF4P7840R240SA

ITEMS

SPEC

UNIT

Center Frequency [fo]

7840.0

MHz

Bandwidth [BW]

fo ±120.0 [7720.0~7960.0]

MHz

Insertion Loss in BW

3.5

dB max

Ripple in BW

1.0

dB max

Return Loss in BW

17.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

 10.0dB min.  @  fo ±  320.0 [ 7520.0 ~8160 ]

MHz

dB min.  @  fo ±     [      &     ]

MHz

dB  min.  @  fo ±   [      &      ]

MHz

dB  min.  @  fo ±   [      &      ]

MHz

Group Delay Variation

ns max

Input Power

2.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
