CFF5P4600R80FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

4600.0

MHz

Bandwidth [BW]

fo ±40.0 [4560~4640]

MHz

Insertion Loss in BW

3.5

dB max

Ripple in BW

1.0

dB max

Return Loss in BW

10.0

dB min

Attenuation

   £ Absolute Value

   R Relative  Value

 40.0 dBc min.  @  fo － 150  [   4550   ]

MHz

40.0 dBc min.  @  fo ＋ 150  [   4760   ]

MHz

dBc min.  @  fo  ±      [          ]

MHz

dBc min.  @  fo  ±      [          ]

MHz

Group Delay Variation

ns max

Input Power

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
