CFN10P2017F2467N15-20FA

ITEMS

ANT >> Low

ANT >> High

UNIT

Center Frequency [fo]

2017.5

2467.0

MHz

Bandwidth [BW]

fo ±7.5 [2010.0~2025.0]

fo ±10 [2457.0~2477.0]

MHz

Insertion Loss in BW

2.5

2.8

dB max

Ripple in BW

1.0

1.0

dB max

Return Loss in BW

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

55.0 dBmin. @ [2457~2477]

60.0 dBmin. [2010~2025]

MHz

45 dBmin. @  [2110 ~2170 ]

8.0 dBmin. [2400~2445]

MHz

25 dBmin. @ [1920 ~1980 ]

 42 dBmin.@ [ 2110~2170]

MHz

34 dBmin. @ [1805 ~1880 ]

32dBmin.@ [ 1920 ~1980 ]

MHz

   dBmin. @  [    ~     ]

35dBmin.@ [ 1805 ~1880 ]

Group Delay Variation

ns max

Input Power

3.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
