CFN10C1783R1878N07FA

ITEMS

ANT >> Low

ANT >> High

UNIT

Center Frequency [fo]

1783.5

1878.5

MHz

Bandwidth [BW]

fo ±3.5 [1780.0~1787.0]

fo ±3.5 [ 1875.0~1882.0]

MHz

Insertion Loss in BW

3.0

3.0

dB max

Ripple in BW

2.0

2.0

dB max

Return Loss in BW

15.0

15.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

65.0 dBmin. @ [1875~1787]

55.0 dBmin. [1780~1787]

MHz

10 dBmin. @  [1765 &1800 ]

10.0 dBmin. [1860&1895]

MHz

  dBmin. @ [    ~    ]

   dBmin.@ [    ~    ]

MHz

  dBmin. @ [    ~    ]

 dBmin.@ [    ~    ]

MHz

Group Delay Variation

ns max

Input Power

3.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
