CFN6P422R05FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

422.5

MHz

Bandwidth [BW]

fo ±2.5  [420.0 ~ 425.0]

MHz

Insertion Loss in BW

4.5

dB max

Ripple in BW

2.5

dB max

Return Loss in BW

10.0

dB min

Attenuation

   RAbsolute Value

   £Relative  Value

18.0 dB min @ fo ±    [417.5  ~     ]

MHz

dB min @ fo ±    [      &     ]

MHz

dB min @ fo ±     [      &     ]

MHz

dB min @ fo ±     [      &     ]

MHz

Group Delay Variation

ns max

Input Power

2.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃  to  +85℃
