CFN8P2137N120FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

2137

MHz

Bandwidth [BW]

fo ±60 [2077~2197]

MHz

Insertion Loss in BW

3.0

dB max

Ripple in BW

1.0

dB max

Return Loss in BW

14.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

30.0dB min @ fo ± 90.0@1967~2307

MHz

45.0dB min @ fo ± 170.0@2047~2227

MHz

dB min @ fo ± [  ~  ]

MHz

dB min @ fo ± [  ~  ]

MHz

Group Delay Variation

ns max

Input Power

2

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
