ITEMS |
ANT >> Low |
ANT >> High |
UNIT |
Center Frequency [fo] |
374.5 |
899.0 |
MHz |
Bandwidth [BW] |
fo ± [100.0~849.0] |
fo ±3.0 [896.0~902.0] |
MHz |
Insertion Loss in BW |
1.0 |
2.5 |
dB max |
Ripple in BW |
0.8 |
0.5 |
dB max |
Return Loss in BW |
14.0 |
16.0 |
dB min |
Attenuation R Absolute Value £ Relative Value |
20 dB min. @ [896~902] |
20 dB min. @[100 ~ 849 ] |
MHz |
dB min. @ [ ~ ] |
dB min. @ [ ~ ] |
MHz |
|
dB min. @ [ ~ ] |
dB min. @ [ ~ ] |
MHz |
|
dB min. @ [ ~ ] |
dB min. @ [ ~ ] |
MHz |
|
Group Delay Variation |
|
ns max |
|
Input Power |
1.0 |
W max. |
|
In/Out Impedance |
50 Ω |
||
Operation Temperature Range |
-40℃ to +85℃ |
