CFF4A5050R100FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

5050.0

MHz

Bandwidth [BW]

fo ±50.0 [5000~5100]

MHz

Insertion Loss in BW

2.5

dB max

Ripple in BW

1.0

dB max

Return Loss in BW

15

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

30.0 dB min.  @ fo ± [6600& 2000.0]

MHz

50.0 dB min.  @ fo ±   [3600 &     ]

MHz

 dB  min.  @ fo ±      [4000& 6000]

MHz

 dB min.  @ fo ±      [   &   ]

MHz

Group Delay Variation

ns max

Input Power

3.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
