CFD4A881R14SA

ITEMS

SPEC

UNIT

Center Frequency [fo]

881.685

MHz

Bandwidth [BW]

fo ±7.0  [874.685 ~ 888.685]

MHz

Insertion Loss in BW

3.0

dB max

Ripple in BW

0.3

dB max

Return Loss in BW

18.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

dB min @ fo ±115.0 [ 766.685 ~966.685  ]

MHz

dB min @ fo ± [  ~  ]

MHz

dB min @ fo ± [  ~  ]

MHz

dB min @ fo ± [  ~  ]

MHz

Group Delay Variation

ns max

Input Power

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
