CFK8P1950N60FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

1950

MHz

Bandwidth [BW]

fo ±30  [1920  ~  1980 ]

MHz

Insertion Loss in BW

2.8

dB max

Ripple in BW

1.2

dB max

Return Loss in BW

18.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

33dB min @ fo ± [ 1900  ]

MHz

            40dB min @ fo ± [  1710  ]

MHz

            45dB min @ fo ± [1710 ~1880]

MHz

50dB min @ fo ± [ 2110~ 2170]

MHz

Group Delay Variation

ns max

Input Power

2

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
