CFF4P942R36SA

ITEMS

SPEC

UNIT

Center Frequency [fo]

942.5

MHz

Bandwidth [BW]

fo±18 [ 924.5 ~960.5 ]

MHz

Insertion Loss in BW

2.7

dB max

Ripple in BW

1.0

dB max

Return Loss in BW

15.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

3.0 dB min.  @fo±  [ 920.0 &    ]

MHz

45.0 dB min.  @fo±  [ 1000.0 &   ]

MHz

  dB min @ fo ±    [    &   ]

MHz

dB min @ fo ±   [     ~   ]

MHz

Group Delay Variation

ns max

Input Power

2.0

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
