CFN8P945N30FA

ITEMS

SPEC

UNIT

Center Frequency [fo]

945

MHz

Bandwidth [BW]

fo ±15 [930~960]

MHz

Insertion Loss in BW

4.0

dB max

Ripple in BW

2dB

dB max

Return Loss in BW

14.0

dB min

Attenuation

   R Absolute Value

   £ Relative  Value

20.0 dB min @ 922.5

MHz

40.0 dB min @ 885~915

MHz

dB min @ fo ± [  ~  ]

MHz

dB min @ fo ± [  ~  ]

MHz

Group Delay Variation

ns max

Input Power

2

W max.

In/Out Impedance

50 Ω

Operation Temperature Range

-40℃ to +85℃
